Description

 Specifications

• Air Ratio: 1:1
• Fluid Inlet/Outlet: 1" NPT
• Max Flow: 37 GPM
• Air Inlet Port: 1/4" NPT
• Body Construction: Aluminum
• Diaphragms: Buna N
• Balls: PTFE
• Seats: Aluminum
• UL Listed: Yes
• Air Consumption: 30CFM @ 50 PSI
• Bolt Pattern: 4.250" X 8.250"
• Height: 15.125"
• Max Particle Size: 1/8"
• Suction Lift- Dry: 15′
• Suction Lift- Wet: 25′
