Description

The FiTech EFI 8 1200 HP Matte Black w/ Force Fuel & CDI Box (93542) is a comprehensive electronic fuel injection (EFI) solution designed for high-performance engines utilizing dual quad intake manifolds. This system is engineered to support up to 1,200 horsepower, making it ideal for both naturally aspirated and boosted applications, including those with 6-71 and 8-71 roots superchargers. It offers a modern replacement for traditional carburetors, providing improved performance, fuel efficiency, and simplified tuning. This kit includes a dual pump Force Fuel delivery master kit and a Go Spark CDI box, ensuring a complete and high-quality upgrade.

KEY FEATURES AND BENEFITS:

• Broad Power Range: Supports engines producing 250 HP to 1,200 HP, making it versatile for various high-performance builds.
• Self-Tuning Capability: Simplifies setup and ensures optimal performance across diverse driving conditions.
• Consistent Fuel Delivery: The dual pump Force Fuel delivery system provides reliable fuel pressure and flow, crucial for high-horsepower applications.
• Ignition Timing Control: Enhances engine management for improved performance.
• Compatibility with Nitrous Oxide: Designed to work seamlessly with nitrous systems.
• Built-in Fuel Pressure Regulator: Maintains stable fuel delivery for consistent performance.
• Precise Fuel Delivery: 80 lbs/hr flow matched injectors and 2.5 BAR internal MAP sensor ensure accurate fuel management.

SPECIFICATIONS:

• Maximum Horsepower: 1,200 HP
• Injection Style: Throttle body
• Timing Control: Yes
• Power Adder Compatible: Yes (Boost/Nitrous oxide)
• ECU Included: Yes
• Fuel Pump Included: Yes (External, 680 LPH)
• Metering Style: Speed density (Map-N)
• Throttle Body Mounting Flange: 4-barrel square bore
• Venturi Diameter: 43.00 mm
• Airflow Rate: 850 CFM
• Injector Size: 80 lbs/hr
• Fuel Type: Alcohol, Gasoline, Methanol, Flex
• Compatibility: Dual quad intake manifolds, including Edelbrock
• CDI Box: Go Spark CDI box included
• Fuel Delivery: Dual pump Force Fuel Delivery Surge Tank Included

HOW TO USE:

• Preparation: Ensure your engine is compatible with a dual quad intake manifold and that you have sufficient space for the throttle bodies and fuel system components.
• Installation: Mount the throttle bodies onto the intake manifold using the provided gaskets and hardware. Connect the wiring harness to the ECU, sensors, and injectors.
• Fuel System Setup: Install the Force Fuel delivery system, including the fuel pump and surge tank. Connect the fuel lines and ensure proper sealing.
• Sensor Connections: Connect the O2 sensor, CTS, IAT, TPS, and MAP sensors to the wiring harness.
• CDI Box Installation: Mount the Go Spark CDI box and connect it to the ignition system.
• Initial Setup: Use the hand-held controller to input basic engine parameters and perform initial calibration.
• Self-Learning: Allow the system to self-learn by driving the vehicle under various conditions. The ECU will automatically adjust fuel and ignition settings.
• Tuning: For advanced tuning, use the Pro-tuning laptop software to fine-tune engine parameters.

BENEFITS OF USING THE FITECH EFI 8 1200 HP MATTE BLACK W/ FORCE FUEL & CDI BOX (93542):

• Improved Engine Performance: Increases horsepower output significantly.
• Enhanced Fuel Efficiency: More efficient than traditional carburetors.
• Simplified Tuning: Self-learning capabilities reduce the need for manual adjustments.
• Consistent Fuel Delivery: Ensured by the dual pump Force Fuel system.
• Precise Ignition Timing Control: Optimizes combustion for better performance.
• Modern Aesthetic: Matte black finish adds a sleek look to your engine bay.

FEATURES:

• Integrated 2.5 BAR MAP Sensor: For accurate air density measurement.
• Dual Fan Control Outputs: For efficient engine cooling management.
• Wide Fuel Compatibility: Supports various fuel types, including alcohol and methanol.
• Hand-Held Controller: Features a 4.5-inch display for easy monitoring and adjustments.
• Speed Density Fuel Management: For accurate fuel delivery calculations.
• 850 CFM Throttle Body Air Flow Rate: Ensures sufficient airflow for high-performance applications.
• Die-Cast Aluminum Throttle Body Construction: Durable and lightweight design.
• Compatible with Standard Dual Quad Air Cleaners: Easy installation and upgrade.
